| Model | Capacity (kg) | Load Centre (mm) | Lifting Height (mm) | Straddle Leg Height (mm) | Min. Fork Width (mm) | Fork Length (mm) | Individual Fork Width (mm) | Platform Size (mm) | OverAdjustable Fork Width (mm) | Effort Force with Load (N) | Load Wheel (mm) | Steering Wheel (mm) | Overall Dimensions (mm) | Net Weight (kg) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| LS80 | 80 | 250 | 1100 | 100 | 70 | 500 | 50 | 500×530×90 | 132-520 | 82 | Φ100×30 | Φ100×30 | 865×550×1470 | 52 | Download |
| LS150 | 150 | 250 | 1100 | 100 | 70 | 500 | 50 | 500×530×90 | 132-520 | 106 | Φ100×30 | Φ100×30 | 830×580×1475 | 62 | Download |
| Model | Capacity (kg) | Height (mm) | Min. Fork H (mm) | Fork Length (mm) | Individual Fork Width (mm) | Fork Width (mm) | Load Wheel (mm) | Steering Wheel (mm) | Net Weight (kg) | |
|---|---|---|---|---|---|---|---|---|---|---|
| PM120 | 120 | 1050 | 95 | 400 | 50 | 345-485 | Ø50×20 | Ø200/50-140 | 31 | Download |
